WBE 700 (600512000) Angle Drill

• Powerful angle drill for drilling in difficult to access areas
• Robust die cast aluminium gear housing for optimum heat dissipation and durability
• Vario-Constamatic (VC)- Electronics for work with materials requiring customised speeds, which remain almost constant under load
• Thumbwheel for speed preselection

Technical Data

Characteristics

• Rated input power: 700 W
• Output power: 305 W
• Drill Ø steel: 10 mm
• Drill-Ø soft wood: 25 mm
• No-load speed: 850 - 2600 rpm
• Speed at rated load: 2300 rpm
• Gears: 1
• Maximum torque: 8 Nm
• Chuck capacity: 1 - 10 mm
• Drill spindle thread: 1/2 " - 20 UNF
• Weight (without power cable): 2 kg
• Cable length: 4 m

Vibration

• Drilling in metal: 2.5 m/s²
• Uncertainty of measurement K: 1.5 m/s²

Noise emission

• Sound pressure level: 90 dB(A)
• Sound power level (LwA): 98 dB(A)
• Uncertainty of measurement K: 5 dB(A)

Scope of Delivery

• Geared chuck
• Chuck key
• Side handle
