KH 18 LTX BL 24 Q (601714840) Cordless combination hammer

• Extremely light and compact cordless hammer with integrated extraction interface
• Maximum drill performance, efficiency and service life thanks to brushless technology and high-performance hammer action
• Dust-free drilling with compact dust extraction ISA 24 (accessory)
• Combination hammer with 3 functions: hammer drilling, drilling and chiselling
• Metabo VibraTech (MVT): integrated damping system to reduce vibrations in order to protect the user's health
• Metabo Quick: quick change between SDS Plus hammer chuck and keyless chuck for many different applications
• Vario-Tacho-Constamatic (VTC)-Full Wave Electronics for work with materials requiring customised speeds, which remain constant under load
• Electronic soft start for precise spot-drilling
• Double safety when the drill bit jams: No kick-back thanks to the mechanic decoupling plus ultra-fast sensor-controlled shutdown
• LED work light for optimum view of the drilling site
• Many brands, one battery pack system: This product can be combined with all 18V battery packs and chargers of the CAS brands: www.cordless-alliance-systems.com

Technical Data

Characteristics

• Battery voltage: 18 V
• Max. single blow energy (EPTA): 2.2 J
• Maximum impact rate: 4750 bpm
• Drill-Ø concrete with hammer drills: 24 mm
• Drill-Ø masonry with core bits: 82 mm
• Drill Ø steel: 13 mm
• Drill-Ø soft wood: 30 mm
• No-load speed: 0 - 1280 rpm
• Tool holder: SDS-plus
• Weight without battery pack: 3 kg

Vibration

• Hammer drilling concrete: 13.4 m/s²
• Uncertainty of measurement K: 1.5 m/s²
• Chiseling: 9.1 m/s²
• Uncertainty of measurement K: 1.5 m/s²

Noise emission

• Sound pressure level: 93 dB(A)
• Sound power level (LwA): 101 dB(A)
• Uncertainty of measurement K: 3 dB(A)

Scope of Delivery

• Hammer chuck for tools with SDS-plus shank end
• Keyless chuck for tools with cylindrical shank
• rubber-coated side handle
• Drilling depth guide
• metaBOX 165 L
• without battery pack, without charger
